| Acid Number, mgKOH/g, max |
0.2 |
0.17 |
ASTM D664 |
| API Gravity at 15.6°C/15.6°C |
Report |
30.4 |
ASTM D1298 |
| Color, ASTM Color Scale, max |
5.0 |
Conforms |
ASTM D1500 |
| Compatibility |
Pass |
Pass |
Paragraph 4.5.1 |
| Copper Strip Corrosion (72 hours at 100 ± 1°C), ASTM Standard, max |
2e |
1b |
ASTM D130 |
| Corrosion Protection (Humidity Cabinet), (100 ± 1 hours at 48.9 ± 1.1°C air temperature) |
|
|
ASTM D1748 |
| Sand-blasted (3 panels) |
Pass |
Pass |
|
| Polished Panels (3 panels) |
Pass |
Pass |
|
| Corrosiveness (Bimetallic Couple) |
Pass |
Pass |
ASTM D6547 |
| Corrosiveness and Oxidation Stability (168 hrs at 121 ± 0.5°C) |
|
|
ASTM D4636 Procedure 2 |
| Metal specimen weight change, mg/cm2, max |
|
|
|
| Cadmium Anode |
± 0.2 |
0.02 |
|
| Steel Grade 1010 |
± 0.2 |
-0.02 |
|
| Aluminum Alloy |
± 0.2 |
0.01 |
|
| Magnesium |
± 0.2 |
0.00 |
|
| Copper (No. 3 max) |
± 0.2 |
0.00 (1b) |
|
| Percent change in viscosity at 40°C |
-5% to +20% |
12.32% |
|
| Change in acid number, max |
0.2 |
0.20 |
|
| Separation of insoluble materials or gumming of the fluid |
None |
None |
|
| Evaporation Loss (22 hours at 100 ±0.5°C), % by weight, max |
75% |
73% |
ASTM D972 |
| Foaming Characteristics |
|
|
|
| Foaming Tendency |
|
|
|
| Foam volume (mL) at end of 5 minute blowing period, max |
|
|
|
| At 24°C |
65 |
0 |
|
| At 94°C |
65 |
10 |
|
| At 24°C after test at 94°C |
65 |
10 |
|
| Foam Stability |
|
|
|
| Foam volume (mL) at end of 10 minute setting period, max |
|
|
|
| At 24°C |
0 |
0 |
|
| At 94°C |
0 |
0 |
|
| At 24°C after test at 94°C |
0 |
0 |
|
| Isothermal secant bulk modulus @ 40°C and 27.6 MPa (4000 psig), MPa (psi) (minimum) |
1379 MPa
(200,000 psig)
|
1606 MPa
(232,931 psig)
|
ASTM D6793
|
| Low Temperature Stability (-54 ± 1°C for 72 hours) |
Pass |
Pass |
FED-STD-3458 |
| Particulate Contamination |
|
|
|
| Particle Count, micrometers, max |
|
|
|
| 5 - 25 |
10,000 |
5,340 |
ASTM D4898 |
| 26-50 |
250 |
10 |
|
| 51-100 |
50 |
8 |
|
| over 100 |
10 |
4 |
|
| Gravimetric method, mg/100 mL, max |
0.5 |
<0.005 |
FED-STD-3012 |
| Pour Point (°C) max |
-59 |
<-72 |
ASTM D97 |
| Rubber Swell, Standard Synthetic Rubber, NBR-L, % (168 ± 0.5 hours at 70 ± 2.5°C) |
19.0% to 31.0% |
19.4% |
ASTM D4289 |
| Shear Stability, percent, max |
Pass |
Pass |
ASTM D2603 |
| Steel-on-Steel wear (average wear scar), mm in diameter, max |
1.0 |
0.74 |
ASTM D4172 |
| Storage Stability (24 ± 3°C for 12 months) |
Pass |
Pass |
FED-STD-3465 |
| Viscosity, mm2/s |
|
|
ASTM D445 |
| At -54°C, max |
3,300 |
2859 |
|
| At -40°C, max |
700 |
559 |
|
| At 40°C, min |
13.2 |
15.6 |
|
| At 100°C, min |
4.6 |
5.45 |
|
| Water, mass %, max |
0.05% |
0.01% |
ASTM D6304 |
